Centri di lavorazione orizzontali Daewoo ACE-H80 CNC
Informazione tecniche
- X-axes1250 mm
- Y-axes1000 mm
- Z-axes1000 mm
- Table dimensions800 x 800 mm
- Max weight on the table2000 kg
- Admission in spindle (ISO)ISO 50
- Power on the spindle25 kW
- ControlFanuc OM
- Number of axes4 axes: X,Y,Z,B
- Toolstoreyes
- Tools90 Toolplaces
- Frequency 20 -> 4500 rpm
- Number of pallets 2
- Power principal motor70 kva
- Length4100 mm
- Depth6850 mm
- Height3240 mm
- Weight18000 kg
- Cooling-systemthrough spindle
Informazioni supplementari
Numero di magazzino: D.02 4196
