Presse ad azione singola a 4 colonne Darragon 100 ton heated

Prodotto aggiunto al suo preferiti

» Richiedere una quotazione presentata personalizzata

Informazione tecniche

Capacity100 ton
Passage between uprights600 mm
Max ram adjustment500 mm
Distance between table -- ram500 mm
Table area600 x 600 mm
Length L -- R1450 mm
Depth Fw -- Bw1250 mm
Height2150 mm

Informazioni supplementari

with 3 heated tables + 2 watercooled tables
max 300° C

Press has been developed to be able to remain under pressure for 24 hours!
Possible to program:
- different temperatures
- holding time of press under pressure
- multiple cycles

Capacity: 100 ton
Passage between uprights: 600 mm
Max stroke: 500 mm
Distance between table -- ram: 500 mm
Table: 600 x 600 mm
Length: 1450 mm
Depth: 1250 mm
Height: 2150 mm
Tipo/Modello: 100 ton heated
Numero di magazzino: M.06 12774
Categoria: [M] Presse idrauliche
Sottocategoria: [M.06] Presse ad azione singola a 4 colonne
Il marchio: Darragon

» Richiedere una quotazione presentata personalizzata

Numero di magazzino: M.06 12774

+++BekijkVideoWerkendeMachine+++

Scaricare tutte le foto in ZIP
