Presse per idroformatura a caldo e freddo Wickert WKP S 400 ton
Informazione tecniche
Informazioni supplementari
Hot press for manufacturing grinding wheels
max temperature: 350° C
Capacity: 400 ton
Max ram adjustment: 500 mm
Table area: 700 x 700 mm
Length: 2125 mm
Depth: 2370 mm
Height: 3500 mm
Options fitted to this press:
> high temperature(350° C)
> heating rod individual monitoring
> 4-zone control
> CNC control
> baffle plate for lower heating plate
> light button on the upper heating plate
> automatic preheating via 2 piece tool temperature sensors
> 2 pieces wear plates for heating plate above and below
> special version control cabinet
> protective grille in special design
> rotary table with integrated ejector
> in and out rails for tool carrier plate with automatic lowering
- Tipo/Modello: WKP S 400 ton
- Numero di magazzino: M.19 12778
- Categoria: [M] Presse idrauliche
- Sottocategoria: [M.19] Presse per idroformatura a caldo e freddo
- Il marchio: Wickert
Numero di magazzino: M.19 12778
