Trumpf TrumaBend V130 130 ton x 3100 mm CNC

Prodotto aggiunto al suo preferiti

» Richiedere una quotazione presentata personalizzata

Informazione tecniche

Capacity130 ton x 3100 mm
BackgaugeCNC
ControlDelem
Passage between uprights2690 mm
Max stroke365 mm
Max distance between table -- ram632 mm
Depth of throat410 mm
Table width120 mm
Locking speed200 mm/sec
Working speed10 mm/sec
Returning speed135 mm/sec
Electric motor (power)19 kW
Power needed380 V
Length3640 mm
Depth2060 mm
Height2375 mm
Weight11,5 ton

Informazioni supplementari

12 axes: Y1 / Y2 / X1 / X2 / R1 / R2 / Z1 / Z2 / T1 / T2 / V / I (= movement of table)
T1 & T2 CNC controlled bending aids
Wila Modufix tooling
Tipo/Modello: 130 ton x 3100 mm CNC
Numero di magazzino: O.01 13071
Categoria: [O] Presse piegatrici, curvatrici, raddrizzatrici, punzonatrici, impianti taglio laser e impianti ossitaglio e linee di profilatura
Sottocategoria: [O.01] Presse piegatrici idrauliche
Il marchio: Trumpf TrumaBend V130

» Richiedere una quotazione presentata personalizzata

Numero di magazzino: O.01 13071

Trumpf TrumaBend V130 130 ton x 3100 mm CNC
