Punzonatrice universale Kingsland 60 ton

Prodotto aggiunto al suo preferiti

» Richiedere una quotazione presentata personalizzata

Informazione tecniche

Punchingcapacity60 ton
Dia x sheetthickness28 x 15 mm
Max course55 mm
Strokes/min26 str/min
Depth of throat220 mm
Max hole dia.110 mm
Worklevel940 mm
Max cutting-thickness in plate200 x 20 / 310 x 15 mm
Bladelength380 mm
90°-cut120 x 120 x 12 mm
45°-cut80 x 8 mm
Worklevel1140 mm
Cut to length round/square40 / 35 mm
Cut to length UFN/IPN profiles102 x 51 mm
Cut to length Profile T80 x 10 mm
Max material -thickness by notching10 mm
Max wide by notching42 mm
Depth V-profile / rectangle100 mm
Electric motor (power)4 kW
Length 1510 mm
Depth 590 mm
Height1570 mm
Weight1250 kg

Informazioni supplementari

Tooling is the same as Geka / Kingsland
Standard punch is dia 22 mm

punching cap: dia 28 x 15 mm / dia 38 x 11 mm
cutting cap: 200 x 20 mm / 300 x 15 mm
angle shear cap: 90° 120 x 120 x 12 mm / 45° 80 x 8 mm
steel bar shear cap: dia 35 / 40 mm
notching cap: 100 x 42 x 10 mm

Bending examples with bending dia (optional): 250 x 15 mm / 500 x 3 mm
Tipo/Modello: 60 ton
Numero di magazzino: P.13 10842
Categoria: [P] Cesoie, punzonatrici universali, linee di taglio trasversale e longitudinale, Lockformer e segatrici a nastro
Sottocategoria: [P.13] Punzonatrice universale
Il marchio: Kingsland

» Richiedere una quotazione presentata personalizzata

Numero di magazzino: P.13 10842
