Torni CNC Leadwell Ø 900 x 2100 mm
Informazione tecniche
- Swing over bed900 mm
- Swing over cross-slide550 mm
- Distance centre tot centre2100 mm
- Max longitudinal travel Z-axis2100 mm
- Max cross travel X-axis425 mm
- Spindle coneA2-11
- Dia of spindle bore117 mm
- Power on the spindle22/30 kW
- Number of speeds4-1500 rpm
- CommandFanuc
- Total power needed70 kVa
- Length5650 mm
- Width2800 mm
- Height2470 mm
- Weight13,4 ton
- Chuck380/500 mm
- Toolchangeryes
- Number of tools12x
Informazioni supplementari
- Tipo/Modello: Ø 900 x 2100 mm
- Numero di magazzino: A.07 8335
- Categoria: [A] Torni
- Sottocategoria: [A.07] Torni CNC
- Il marchio: Leadwell
