Toolmaster TM250 tool presetter
Additional info
Tool Master 250 T-CAM2
X-axis: 300 mm
Z-axis: 360 mm
weight: 176 kg
The digital
CMOS-camera with telecentric objective probes the tool tip and transmits the
live image to a transflective 3.5" TFT-colour display. The electronic maximum
search allows the tip to be rotated through the maximumg diameter (vertex). The
measuring process is supported by positioning flags which appear when optimum
congruence is achieved between tool contour and an axis of the reticule. Measurements
can therefore be performed to a repetitive accuracy of +/-2 microns without
operator involvement. The measuring process is extremely simple and is no
different from the use of a profile projector. The operator consequently has no
influence on the measuring result, thereby ensuring highest possible measuring
reliability. Any desired radius or angle can be displayed on the screen by
means of a knob.
- Type/Model: TM250 tool presetter
- Stocknumber: W.01 14183
- Main category: [W] Measuring and Testing equipment, Balancing machines
- Sub category: [W.01] Vertical digitizing & coordinating measuring Machines
- Brand: Toolmaster
