Schiess 80 DF Ø 9000 x 5547 mm CNC
Дополнительная информация
Schiess 80 DF
Type: 80 DF 700/900-550/280
Original CNC machine from Schiess (not a conversion from conventional to CNC)
Fully hydrostatic machine
Welded column
Siemens motor
Equipped with operator lift to be able to see top of workpiece
Very high tolerance machine
Table diameter: 7000 mm
Max diameter of workpiece: 9000 mm
Max load: 315 ton
Speed: 0,25 > 25 rpm
Max rotational torque: 63 000 kgm
Max cutting force with ram extended to 900 mm: 12 500 kg
Toolhead can incline -40° to +40°
Power: 125 kW
weight of table: 71 ton
Ram section: 380 x 380 mm
Horizontal travel of ram from center of table: 5640 mm
Vertical travel of ram: 2800 mm
Max height under cross-beam: 5547 mm
Horizontal travel of cross-beam: 4700 mm
Equipped with automatic toolchanger with 3 positions
Total weight of machine: 260 ton!
Unique feature >> there are 3 possible configurations of the main column:
1 - for max swing 9000 mm (how it's currently set up)
2 - for max swing 10 500 mm
3 - for max swing 13 100 mm
This can be achieved by repositioning the main column on the foundation.
- Тип модели: Ø 9000 x 5547 mm CNC
- Номер каталога: A.12 14134
- Главная категория : [A] Токарные станки
- Подкатегория: [A.12] Станки токарно-карусельные вертикальные с ЧПУ
- Производитель: Schiess 80 DF
Номер каталога: A.12 14134
